Sea Water Activated Cell
1.5 Volts
|
Technical Specification :
The Sea Water Activated Cell generate 1.5 V. It for
Life Raft Cell & can be discharged at 160 mA current for12
hours. The overall dimension is 93 x 26 x 12 mm and
maximum weight 40 grams with Light unit.
Construction :
Life Raft Cell is consists of a moulded ABS polymer
container with two activation holes and containing silver
chloride and magnesium plates as Anode and Magnesium as
Cathode. The Sea Cell is working at wide range of
temperature and humidity the water act as electrolyte.
Operation :
To activate the Cell, sealing plug must be removed
by pulling the cord. On immersion in water, activation
will take place within 30 seconds. Once the cell has been
unsealed and immersed in water it must be considered as
discharged.
Approval :
The Life Raft Cell is approved by Indian Navy. |
|
|

 |
